Monarch Pro™
Features
- Cost-effective
- Small size
- High resolution
- Versatile specification
- Plug & Play Connection
- APK for data collection
- Robust Aluminium casing
- Waterproof & Oilproof
Monarch Pro thrives amidst vibrations, shocks, humidity, and a variety of environmental conditions, ensuring reliable performance in any scenario.
Specifications
| Monarch Pro™ | |
| Sensor Characteristics: | |
| Sensor type | Global shutter, B/W, CMOS (1/5”) |
| Preview mode | 60fps |
| Cube acquisition (10 bands) | 750ms (@1ms exposure) |
| Resolution (H x V) | 1280 x 1024 |
| Exposure time | 1 - 500ms |
| Gain | x1 - x10 |
| F-Number | 4.7 mm |
| Effective focal length | 4.98 mm |
| H-FOV (H, V, D) | 31.5°, 25.5°, 39.8° |
| Spectral Characteristics: | |
| 10 CWL bands (±10nm) | 713,736,759,782,805,828,851, 874, 897, 920nm |
| CWL FWHM (±15nm) | 30nm |
| AOI dependency (average) | -1.1 nm/degree |
| System Specifications: | |
| Operating temperature | 15-35°C (non-condensing) Thermal shift of (-)1.1nm / °C |
| Storage Temperature | 10°C - 50°C (non-condensing) |
| IP Level | 55 |
| Input voltage | 5V DC |
| Power consumption | < 1.6W (peak) |
| Dimensions | 64 x 50 x 20 mm |
| Weight | 50g |
| Interface | USB-C |
| Saved Data format | 10bit ENVI, 8bit PNG |
| Software - Data collection: | |
| Monarch Application | Windows 10 & 11 (64bit) |
| Windows API | C / Python |
| Linux API | C / Python |
Applications
Food quality
Agriculture
Biomedical
Recycling
Pharmaceuticals
Art analysis
Forensics
